Hyundai Santa FE 2023 1.6T
Hyundai Santa FE 2023 1.6 hybrid description
Hyundai Santa FE 2023 1.6T is being produced from 2024. It has four-cylinder engine with displacement of 1.6 litres, which produces power of 160 horsepower on 5500 rpm and torque 265 Nm (Newton metres) on 1500 revolutions per minute.
This 4-cylinder 16-valve engine camshaft is driven by chain (What is an engine chain and belt? ). Engine has fuel injection system and turbine. The engine meets the Euro 6 emissions standard. Approximate engine life expectancy (mileage until serious repairs are required) for this engine is between 220 000 and 370 000 kilometres. Note that engine life can be longer or shorter depending on maintenance.
More engine specs
This Hyundai Santa FE 1.6 engine oil type is 5W-30 and oil capacity is 4.8 litres.
Hyundai Santa FE 2023 1.6T has AWD (all wheel drive) (power is automatically distributed between the wheel axles) and automatic gearbox with 6 gears.
Hyundai Santa FE 2023 1.6T accelerates to speed 100 kilometres per hour in 9.3 seconds. The maximum speed of this car is 180 km/h.
Hyundai Santa FE 2023 1.6T technical data
| Model: | Hyundai Santa FE 1.6T | ||
|---|---|---|---|
| Body style: | Crossover / SUV | ||
| Production period: | 2024. January | ||
| Engine: | 1598 cm3 Hybrid, 4 cylinders | CO2 emissions: | no data |
| Power: | 160 HP ON 5500 RPM | Torque: | 265 NM ON 1500 RPM |
| Gearbox: | Automatic gearbox (6 gears) | Drive type: | All wheel drive (AWD, 4x4) |
| Top speed: | 180 km/h | Acceleration 0-100 km/h: | 9.3 seconds |
| Fuel consumption (l/100km): | no data | ||
| Fuel tank capacity: | 47 litres (12.4 gallons) | ||
| Car dimensions: | 4.83m (length) 1.90m (width) 1.78m (height) | ||
| Turning diameter: | 11.6 meters | ||
| Trunk capacity: | 985 litres | ||
| Trunk max capacity: | 1949 litres (with rear seats folded down) | ||
| Gross weight: | 2740 kg | ||
Hyundai Santa FE 2023 1.6T engine G4FU
Engine reliability:
Overall, this engine can last around 220,000 to 370,000 km if properly maintained, using the correct quality oil and fuel, and carrying out regular checks and maintenance.| Engine displacement | 1598 cm3 |
|---|---|
| Number of cylinders | 4 |
| Bore (cylinder diameter) | 75.6 mm |
| Stroke length (piston move) | 89 mm |
| Compression ratio | 10.5 : 1 |
| Camshaft drive | Timing chain Chain motors are considered more reliable, chain replacement usually is required less often than a timing belt, but they are often louder and vibrate more. |
| Fuel system | Injection |
| Hyundai Santa FE 2023 1.6T oil type | 5W-30 |
| Oil capacity | 4.8 litres (5.1 quarts) |
| Power | 150 - 180 HP ON 5500 RPM |
| Torque | 250 - 265 NM ON 1500 RPM |
| Start of production (year) | 2020 |
| Duration of production | 6 years |
| Engine also used on | Hyundai Tucson |
All Hyundai Santa FE crossover [2023 modifications
| Modification | Engine | Power | Consumption | Drive type |
|---|---|---|---|---|
| Hyundai Santa FE 2024 1.6T Jan 2024 — | 1.6 Hybrid | 160 HP | - | Front wheel |
|
Hyundai Santa FE 2024 1.6T 4x4
Jan 2024 — Most dynamic version - 100 km/h in 9.3 seconds |
1.6 Hybrid | 160 HP | - | All wheel |
| Hyundai Santa FE 2024 1.6T 4x4 Jan 2024 — | 1.6 Hybrid | 160 HP | - | All wheel |
| Hyundai Santa FE 2023 1.6 Smartstream | 1.6 Hybrid | 180 HP | - | Front wheel |
| Hyundai Santa FE 2023 1.6 Smartstream 4x4 | 1.6 Hybrid | 180 HP | - | All wheel |
|
Hyundai Santa FE 2023 2.5 Smartstream
Most fuel efficient version |
2.5 Petrol | 281 HP | 10.0 l/100km | Front wheel |
| Hyundai Santa FE 2023 2.5 Smartstream 4x4 | 2.5 Petrol | 281 HP | 10.6 l/100km | All wheel |
